Belt Conveyors
Westfield WCX Belt Conveyors
Westfield Belt Conveyors are engineered to be rugged and reliable while being gentile on delicate crops like chickpeas and soybeans. Designed for high capacity while minimising damage and helping to protect seed quality.
Field Loaders
AGI Westfield Field Loaders are gentle on crops while delivering maximum performance.
1500 & 2400 Series Belt Conveyors
Westfield 1500 and 2400 Series belt conveyors offer gentle handling with low maintenance and high capacity.
Low Profile Transfer & Portable Pits
AGI Westfield have a range of transfer belts, Pitstop portable drive over pits and swing away belt options.
WCX3 FMD Field Loader
Westfield WCX 15:49 FMD Field Loader
The Westfield WCX3 Field Loader includes all the benefits of a standard belt conveyor but features an extended low profile hopper that makes it easy to get in under silos. The 15 inch belt running in a 10 inch tube gives a maximum capacity of 245 tons per hour.
The WCX3 Field Loader has a turbo clean wash system allowing it to to handle tough products like fertliser and canola. The new IBEX Mover Kit makes moving the WCX3 Field Loader a breeze.
Top Drive Field Loader
Westfield 15:49 Top Drive Field Loader
The AGI Westfield Top Drive Field Loader features the same extended low profile hopper as the FMD and is available in Electric or Hydraulic drive.
1500 Series Belt Conveyors
The Westfield WCX 1500 Series Belt Conveyors are available in 67 to 102 foot lengths.
Models - 15:67 15:77 15:87 15:102
The Westfield 1500 Series Belt Conveyors are available in 67, 77, 87 and 102 foot lengths. The 67,77 and 87 models are motor driven with scissor lift undercarriage and hydraulic mover kits. The 100 foot model is PTO driven. A Swing Away option is also available.
The Westfield 1500 Series have a 15" belt running in a 10" tube and are capable of 160 tons per hour. They come standard with weather guards, plastic hood and collapsible canvas hopper.
2400 Series Belt Conveyors
The Westfield WCX 2400 Series Belt Conveyors are available in 95 to 120 foot lengths.
Models - 24:95 24:105 24:120
The Westfield 2400 Series Belt Conveyors use a 23.5 inch belt running in a 14 inch tube to give a maximum output of 6 tons per hour. Available in lengths from 95 foot to 120 foot with dual cylinder hydraulic scissor lift on 95' model and a newly designed heavy duty undercarriage for 105 and 120' models. The Westfield 2400 Series are available with Side PTO and Swing Away options.
Low Profile Transfer
Westfield 15:15 LP Transfer
Featuring a 7½" hopper clearance, 9" clearance at the transition and a discharge height of 28" the Westfield 15:15 Low Profile Transfer is perfect for getting between trailers on B-double and Road Trains.
Swing Away Option
Available for 1500 and 2400 Series.
The low profile Swing Away with collapsible hopper is available for the 1500 and 2400 series conveyors. Featuring a center mounted CV PTO shaft with gearbox drive system, standard with hydraulic winch. The swing conveyor is hydraulicly driven and requires approximately 12 GPM on 1500 series, 18 GPM on 2400 series.
2400 Pitstop
Westfield 2400 Portable Drive Over Pit
The Westfield 2400 Series Pitstop has a 7.5" clearance and a maximum capacity of 380 tones per hour and a discharge height of 36". Available in hydraulic or electric drive.
